Create New Floor Space Without Major Civil Works
Pre-engineered MS steel mezzanines with tailored loading, decking, stairs and safety rails. Ideal for warehouses, retail and offices. Free site visit & quotation across all Emirates.
What Are MS Steel Mezzanine Floors?
Mezzanine floors are elevated platforms built from mild steel columns and beams to create extra usable space above the main floor. They’re fast to deploy, highly configurable, and supplied with compliant staircases, guardrails, loading gates and your choice of decking.
Key Characteristics
Modular Steel System
Bolted MS frames sized for spans, loads and clearances.
Engineered Loading
Typical 3–10 kN/m²; higher loads project-specific.
Decking Options
Chequer plate, grating or deck boards with vinyl/epoxy finishes.
Safety & Access
Stairs, guardrails, mid-rails, toe-boards and loading gates.
Durable Finishes
Primer + PU/powder coat; galvanized options for humid zones.
Common Uses
- Warehouse storage platforms & pick mezzanines
- Retail back-of-house and showrooms
- Offices/meeting pods above production floors
- Plant platforms for equipment & services
Technical Specifications
Load Class
3.0–10.0 kN/m² (higher on request; project-specific calcs).
Spans
Typical 3–8 m between columns (layout-dependent).
Clear Height
Set for forklift/pallet jack or office use under the deck.
Decking
Chequer plate, grating, or deck board + vinyl/epoxy finish.
Stairs/Rails
Code-compliant stairs, guardrails, toe-boards and gates.
Finish
PU paint or powder coat; galvanized option for corrosion control.
Documentation
GA drawings, load data, method statement and certificates.
Detailed Specification Table
| Structure | MS columns, primary/secondary beams (bolted), bracings as required |
|---|---|
| Design Loads | Uniform load 3–10 kN/m²; point/load strips as per usage |
| Spans / Grid | 3–8 m typical; grid optimized for aisles, stairs and operations |
| Decking | Chequer plate / steel grating / deck board with finish (vinyl/epoxy) |
| Staircases | Stringers, treads, landings with handrails, mid-rails, toe-boards |
| Guardrails | Perimeter rails, loading gates (swing/pallet safety gates) |
| Finish | Primer + PU/powder coat; hot-dip galvanizing optional |
| Deliverables | GA drawings, load schedule, anchor details, method statement |
| Fire Strategy | Project-dependent; options for protected steel and fire-rated decks |
| Compliance | Local authority requirements; structural calcs and certificates |
Final member sizes, column layout and deck specification are confirmed after site survey, usage brief and approved GA drawings.
Options & Upgrades
Loading Gates
Swing, pallet safety or sliding gates for safe loading.
Floor Finishes
Vinyl, epoxy, anti-slip coatings and hygiene-grade options.
Fire & Protection
Steel protection/encasement and fire-rated deck systems.
Lighting & Services
Under-deck lighting, cable trays and service penetrations.
Integration
Interfaces for conveyors, lifts and racking systems.
Installation Process
Site Survey
Measure spans, column grid, slab capacity and clear heights.
Design & Approval
GA drawings, load calcs, stair locations and finishes.
Fabrication
Cutting, drilling, surface treatment and QA checks.
Erection
Columns, beams, bracings, deck and rails installed safely.
Inspection
Load checks, bolt tightening, finish and safety verification.
Handover
As-builts, certificates and maintenance briefing.
Comprehensive Services
Custom Design
Grid, spans and decking optimized for your operations.
Installation
Fast, safe erection with quality control and supervision.
Maintenance
Periodic inspections, touch-ups and safety audits.
Modernization
Extensions, re-grid and integration with new equipment.
Our Service Process
- Consultation: Usage, load class, spans and finishes.
- Design: GA drawings, calcs, stairs/rails and services.
- Execution: Fabrication, erection and finishing.
- Aftercare: Training, AMC and periodic inspections.
Civil Works & Deliverables
By Client / Builder
- Slab load verification and anchors per GA
- Power, lighting and clear work area for erection
- Fire/life-safety provisions as per authority
- Openings/penetrations for services if required
By Gulf Tech Elevators
- GA drawings, load schedule and anchor details
- Structure supply, installation and finishing
- Safety rails, stairs and loading gates
- O&M manuals, certificates and handover docs
Service Areas
We serve all UAE Emirates: Dubai, Abu Dhabi, Sharjah, Ajman, Al Ain, Ras Al Khaimah, Umm Al Quwain, and Fujairah.
Project Gallery
Frequently Asked Questions
Can the mezzanine be extended later?
Yes—modular grids allow future bays and deck expansions.
What about fire requirements?
We propose a strategy based on authority rules—options include protected steel and fire-rated decks/ceilings.
Is the deck suitable for trolleys/pallets?
Yes—specify the load class and choose chequer plate or suitable board with finish for rolling loads.
